Low Noise Amplifiers

Freshfield Microwave Systems utilise the latest HEMT and GaAs FET technology to achieve high performance Low Noise Amplifiers which can be produced both quickly and cost effectively.

Options Include

Temperature Compensation

Input Limiter Protection

Phase Tracking/Matching

Gain Tracking/Matching

Built In Test

Limiting

Examples of available LNA's

Frequency Range	Noise Figure	Gain	Power (-1dB GCP)
1.2 - 1.4GHz	0.7dB	40dB	+15dBm
2.7 - 3.1GHz	0.8dB	35dB	+15dBm
4.4 - 5.0GHz	0.9dB	40dB	+18dBm
7.25 - 7.75GHz	0.9dB	42dB	+12dBm
11.7 - 12.2GHz	1.1dB	40dB	+12dBm
12.2 - 12.8GHz	1.3dB	40dB	+12dBm

Wide range of Low Noise Amplifiers are available. E-mail or Fax us your requirements.
